Export a longitudinal profile to dxf
ZuluDrain Online Help «Export a longitudinal profile of a wastewater disposal system»
A longitudinal profile of a wastewater disposal system is exported to an Autocad file format – DXF. The profile table is filled in automatically based on the information stored in the database and displayed on the map. The look of the profile, vertical and horizontal scale, sheet format, well width, line weight and text height are configured by the user.
When building a profile of a sewer main, it is possible to automatically build profiles for all adjacent pipes. The longitudinal profile also shows intersections with other utility networks displayed on the map.
